CHEMICAL COMPOSTION (%)
Name	Chromium (Cr)	Carbon (C)	Nickel (Ni)	Manganese (Mn)	Nitrogen (N)	Phosphorous (P)	Sulphur (S)	Silicon (Si)	Molybdenum (Mo)	Copper (Cu)	Iron (Fe)
904L	19.0-23.0	0.02	23.0-28.0	2			0.045 Max	4.0 Max.	4.0-5.0	1.0-2.0 Max.	Balance
254-SMO	19.5–20.5	0.02 Max.	17.5–18.5	1.0 Max.	0.18–0.25 Max.	0.03 Max.	0.01 Max	0.8 Max.	6.0–6.5	0.50–1.00 Max.	Balance
654-SMO	24.0-25.0	0.020 max	21.0-23.0	2.00-4.00	0.45-0.55	0.030 max	0.005 max	0.50 max	7.0-8.0	0.30-0.60	Balance
AL-6XN	20.00-22.00	0.03 Max.	23.50-25.50	2.00 Max.	0.18-0.25	0.040 Max.	0.030 Max.	1.00 Max.	6.00-7.00	0.75 Max.	Balance
4565	23.0–26.0	0.03 Max.	16.0–19.0	3.5–6.5	0.3–0.6			1.00 Max.	3.5–5.0		Balance

Process

Weaving pattern:

1.Plain weave
2.Twill weave

Surface Finishing: NA

Key Properties

• Very good resistance to uniform corrosion
• Good to exceptionally good resistance to pitting and
crevice corrosion
• Very good resistance to various types of stress
corrosion cracking
• Good ductility
• Good weldability

Typical Applications:

• Process equipment in chemical industry
• Bleaching equipment in the pulp and paper industry
• Flue gas cleaning
• Desalination
• Seawater handling
• Hydrometallurgy
• Food and beverage
• Pharmaceuticals
• Heat exchangers

Specifications

2mesh/inch-500mesh/inch General;
We produce wire cloth in all kinds of forms. The weaving style is determined according to our customers’ specific requirements, such as the material, the wire diameter, the size of the mesh, width and length.
Wire mesh specifications of Super Austenitic Stainless Steel

Mesh		S.W.G	Aperture (mm)	Wire Diameter (mm)	Effective (%)	Weight (Kg/m2)
Inch	CM	S.W.G	Aperture (mm)	Wire Diameter (mm)	Effective (%)	Weight (Kg/m2)
3mesh	1.18	14	6.27	2.2	62	7
3mesh	1.2	18	7.25	1.219	70	2.5
3.5mesh	1.4	20	6.34	0.914	66	1.8
4mesh	1.57	16	4.72	1.63	58	5
4mesh	1.6	20	5.45	0.914	76	2.1
4.5mesh	1.8	22	4.93	0.711	71	1.2
5mesh	1.97	18	3.86	1.22	57	3.6
5mesh	2	22	4.36	0.711	76	1.3
6mesh	2.36	18	3.04	1.22	50	4.3
6mesh	2.36	22	3.52	0.711	63	1.6
8mesh	3.15	20	2.26	0.91	43	3.2
8mesh	3.15	24	2.5	0.559	67	1.5
10mesh	3.94	20	1.63	0.91	41	4
10mesh	3.94	26	2.08	0.46	67	1.1
12mesh	4.72	22	1.41	0.71	43	2.9
12mesh	4.72	26	1.74	0.457	68	1.4
14mesh	5.52	26	1.36	0.46	57	1.4
16mesh	6.3	28	1.21	0.376	55	1.2
18mesh	7.09	30	1.1	0.315	60	0.85
20mesh	7.87	30	0.95	0.315	58	0.95
22mesh	8.66	32	0.88	0.274	57	0.8
24mesh	9.45	32	0.78	0.274	55	0.85
26mesh	10.2	32	0.74	0.274	51	0.7
28mesh	11	34	0.67	0.234	50	0.75
30mesh	11.8	34	0.61	0.234	48	0.8
32mesh	12.6	34	0.56	0.234	50	0.84
36mesh	14.2	34	0.47	0.234	45	0.95
38mesh	15	36	0.48	0.193	46	0.7
40mesh	15.7	36	0.44	0.193	50	0.8
50mesh	19.7	38	0.36	0.152	46	0.58
60mesh	23.6	40	0.3	0.122	50	0.45
80mesh	31.5	40	0.198	0.12	44	0.58
100mesh	39.4	42	0.154	0.1	37	0.5
120mesh	47.2	44	0.13	0.081	40	0.39
130mesh	51.2	45	0.125	0.07	41	0.325
140mesh	55.1	45	0.111	0.07	38	0.35
150mesh	59.1	46.5	0.115	0.055	48	0.206
160mesh	63	46	0.097	0.61	32	0.3
170mesh	66.93	47	0.09	0.05	41	0.213
180mesh	70.9	47	0.09	0.051	410	0.24
190mesh	74.8	47	0.083	0.051	40	0.24
200mesh	78.7	48	0.086	0.041	46	0.17
220mesh	86.6	48	0.074	0.041	41	0.19
240mesh	94.5	48	0.065	0.041	39	0.2
250mesh	98.4	48	0.061	0.041	38	0.22
260mesh	102.4	48	0.057	0.041	34	0.22
280mesh	110.2	49	0.06	0.031	31	0.14
300mesh	118.1	49	0.054	0.031	40	0.15
320mesh	126	49	0.048	0.031	39	0.16
350mesh	137.8	49	0.042	0.031	36	0.16
400mesh	157.5	50	0.0385	0.025	39	0.013
450mesh	177.2	50	0.0314	0.025	37	0.14
500mesh	196.6	50	0.0258	0.025	35	0.156
